US Duct 480V Three Phase Mechanical Shaker 10HP Medium-Size Open Baghouse Tri-Bag Dust Collector LOBH-10

Description

The Legend APC Open Baghouse Collector is ideal for removing particulates from industrial air streams. They come in three sizes ranging from 2000-5000 CFM. Designed for woodworking, plastic, and other dry dust collection. US Duct products will maintain optimum efficiency no matter how tough the job is.

Applications

• Ideal for woodworking, plastics, and other dry dusts
• Not recommended for sanding applications

Filter Material

100% polyester, woven, Beane-style bag with texturized filament. Carbon yarn is knitted into the yarn to protect against static buildup.

Features

• Mechanical shaker for fast and easy bag cleaning
• Sized and designed for indoor use. See National Fire Protection Association guidelines and the local Authority Having Jurisdiction for details
• Includes a push-button manual starter
• Comes with bag or barrel discharge options
• Small footprint
• Arrives practically ready to use – bolt it to the floor, connect the duct, plug it in, and start working

Specifications

• Airflow Capacity
  • Min: 4000 CFM
  • Max: 4500 CFM
• Pressure Drop
  • Min: 7.8” WG
  • Max: 6.0” WG
• Motor Power: 10 HP
• Filtration Area: 245 ft²
• Filter Bags (count): 24
• Discharge Ports: 3 @ 18”
• Discharge Options: Bags
• Inlet: 16”
• Footprint: 45”x95”
• Height: 107”
• Electrical Requirements: 480V Three Phase
• Weight: 740 lbs

 Optional Add-Ons

• Closed Canister Discharge Barrels
• Fume Arms, various sizes
• Standard Fume Extractors, various sizes
• Cleaning Fume Extractors, various sizes
• Cleaning and HEPA Fume Extractors, various sizes
