Castaly Industries 14” Two Slide Auto Line Copy Shaper CS-145-2T

Features

• CS-145-2T is a two-vertical-shaft profiling machine used for curved and two-side profile moulding of furniture products.
• Workpieces are placed on the template during processing, and auto feeding driven by the rubber roller.
• The machine incorporating a copy mechanism by pneumatic power to cut the profile modeling of the pieces according to the template shapes.
• Variable feed speed control for the best finish result.
• Feeding speed is 0 ~ 92 FPM.
• Two spring hold-down rolls to keep the workpiece tight without slipping.
• This machine can be operated safely and quickly by less setup, causing no trouble, and can replace conventional template easily.
• Excellent model for furniture and woodworking industries.

Specifications

• Max. Working Width: 14″
• Max. Working Length: —
• Min. Working Length: 10″
• Max. Working Height: 5″
• Shaper Spindle Speed: 10000 PM
• Shaper Spindle Dia.: 1¼”
• Shaper Motor: 5 HP x 2
• N.W.: 1930 LBS
• G.W.: 2350 LBS
